Komatsu D51EXi-22 and D51PXi-22 (SN from B13500) Crawler Dozers with 6D107E-1 engines (Brazilia) Workshop Manual (KEBM028601)

Illustrated factory Workshop Manual for Komatsu Crawler Dozers Models D51EXi-22 and D51PXi-22.

This manual will assist you in diagnosing, repairing, and adjusting for your crawler dozer.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models (Brazilia):
   D51EXi-22 (SN: B13500-)
   D51PXi-22 (SN: B13500-)

Format: PDF, 1574 pages
Language: English
Table of Contents:
   INDEX AND FOREWORD
      INDEX
      FOREWORD, SAFETY AND GENERAL INFORMATION
   SPECIFICATION
      TABLE OF CONTENTS
      SPECIFICATION DRAWING
      SPECIFICATION
      WEIGHT TABLE
      TABLE OF FUEL, COOLANT AND LUBRICANTS
   STRUCTURE AND FUNCTION
      TABLE OF CONTENTS
      ENGINE AND COOLING SYSTEM
      POWER TRAIN
      DAMPER
      HST HYDRAULIC EQUIPMENT ARRANGEMENT DIAGRAM
      STEERING AND BRAKE CONTROL
      MOTOR CONTROL VALVE
      SOLENOID VALVE
      EPC VALVE
      CHARGE PUMP
      FINAL DRIVE
      UNDER CARRIAGE AND FRAME
      HYDRAULIC SYSTEM
      WORK EQUIPMENT
      RIPPER
      PISTON VALVE FOR ANGLE CYLINDER
      CAB AND ITS ATTACHMENTS
      ELECTRICAL SYSTEM
      SYSTEM COMPONENTS
      SENSORS
   STANDARD VALUE TABLES
      TABLE OF CONTENTS
      STANDARD VALUE TABLE FOR ENGINE
      STANDARD VALUE TABLE FOR CHASSIS
      STANDARD VALUE TABLE FOR ENGINE
      STANDARD VALUE TABLE FOR CHASSIS
      STANDARD VALUE TABLE FOR ICT
      PERFORMANCE MEASURING POSTURE AND METHOD
      TABLE OF CONTENTS
      RELATED INFORMATION ON TESTING AND ADJUSTING
      ENGINE AND COOLING SYSTEM
      HANDLING CONTROLLER HIGH-VOLTAGE CIRCUIT
      FUEL SYSTEM
      POWER TRAIN
      PARKING BRAKE LEVER
      BRAKE PERFORMANCE
      BRAKE PEDAL LINKAGE
      EMERGENCY RELEASE OF PARKING BRAKE
      DECELERATOR PEDAL
      UNDERCARRIAGE AND FRAME
      HYDRAULIC SYSTEM
      WORK EQUIPMENT
      ELECTRICAL SYSTEM
   TESTING AND ADJUSTING
   TROUBLESHOOTING
      TABLE OF CONTENTS
      RELATED INFORMATION ON TROUBLESHOOTING
      TROUBLESHOOTING BY FAILURE CODE
      TROUBLESHOOTING OF ELECTRICAL SYSTEM (E-MODE)
      TROUBLESHOOTING OF HYDRAULIC AND MECHANICAL SYSTEM (H- MODE)
      TROUBLESHOOTING OF ENGINE (S-MODE)
   DISASSEMBLY AND ASSEMBLY
      TABLE OF CONTENTS
      RELATED INFORMATION ON DISASSEMBLY AND ASSEMBLY
      CONNECTOR REPAIR PROCEDURES
      NOSE GUARD (HOOD)
      MUFFLER AND EXHAUST STACK
      CAB AND ITS ATTACHMENTS
      AIR CONDITIONER/HEATER
      FOOT HEATER
      ENGINE AND COOLING SYSTEM
      ENGINE AND HST PUMP
      DRIVE DAMPENER
      HST PUMP OVERHAUL PROCEDURES
      WORK EQUIPMENT PUMP OVERHAUL PROCEDURES
      DIESEL ENGINE OVERHAUL PROCEDURES
      TRACK SYSTEM
      FIELD DISASSEMBLY AND ASSEMBLY OF ONE LINK (CONVENTIONAL TYPE TRACK SHOE)
      FIELD DISASSEMBLY AND ASSEMBLY OF ONE LINK (PLUS TYPE TRACK SHOE)
      TRACK FRAME
      FRONT TRACK IDLER
      TRACK ROLLER
      FINAL DRIVE
      FINAL DRIVE OVERHAUL PROCEDURES
      TRAVEL MOTOR OVERHAUL PROCEDURES
      FAN MOTOR
      FAN MOTOR OVERHAUL PROCEDURES
      DB 12 VALVE
      COOLING PACKAGE
      FUEL TANK
      HYDRAULIC TANK
      WORK EQUIPMENT
      CYLINDER OVERHAUL PROCEDURES
      WHOLE DISASSEMBLY AND ASSEMBLY OF TRACK SHOE (PLUS TYPE TRACK SHOE)
   OTHERS
      TABLE OF CONTENTS
      CONNECTOR ARRANGEMENT DRAWING AND ELECTRICAL CIRCUITDIAGRAM
      HYDRAULIC SYSTEM
      ELECTRICAL SYSTEM
