Komatsu 930E-2 (SN: A30296-30297; A30300) Electric Dump Trucks (USA) Workshop Manual (CEBD012201)

Illustrated factory Workshop Manual for Komatsu Electric Dump Trucks Models 930E-2.

This manual will assist you in diagnosing, repairing, and adjusting for your electric dump truck.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models (USA):
   930E-2 (SN: A30296-30297; A30300)

Format: PDF, 935 pages
Language: English
Table of Contents:
   GENERAL INFORMATION
      MAJOR COMPONENT DESCRIPTION
      GENERAL SAFETY AND OPERATING INSTRUCTIONS
      WARNINGS AND CAUTIONS
      STANDARD CHARTS AND TABLES
      STORAGE AND IDLE MACHINE PREPARATION
   STRUCTURES
      STRUCTURAL COMPONENTS
      DUMP BODY
      FUEL TANK
   ENGINE
      POWER MODULE
      COOLING SYSTEM
      POWERTRAIN
      AIR CLEANERS
      FAN CLUTCH
   ELECTRICAL SYSTEM (24VDC NON-PROPULSION)
      VDC ELECTRIC SUPPLY SYSTEM
      VDC ELECTRICAL SYSTEM COMPONENTS
      BATTERY CHARGING ALTERNATOR
   ELECTRICAL PROPULSION SYSTEM
      ELECTRICAL PROPULSION SYSTEM COMPONENTS
      AC DRIVE SYSTEM ELECTRICAL CHECKOUT PROCEDURE
   REAR AXLE, SPINDLES AND WHEELS
      TIRES AND RIMS
      FRONT WHEEL HUB AND SPINDLE
      REAR AXLE HOUSING ATTACHMENT
      REAR AXLE HOUSING
   HYDRAIR II SUSPENSIONS
      FRONT SUSPENSIONS
      REAR SUSPENSIONS
      SUSPENSION OILING AND CHARGING PROCEDURE
   BRAKE CIRCUIT
      BRAKE CIRCUIT
      BRAKE CIRCUIT COMPONENT SERVICE
      BRAKE CIRCUIT CHECK-OUT PROCEDURE
      WET DISC BRAKE ASSEMBLY
      PARKING BRAKE
   HYDRAULIC SYSTEM
      HYDRAULIC SYSTEM
      HYDRAULIC SYSTEM COMPONENT REPAIR
      STEERING CIRCUIT
      STEERING CONTROL UNIT
      STEERING CIRCUIT COMPONENT REPAIR
      HOIST CIRCUIT
      HOIST CIRCUIT COMPONENT REPAIR
      HYDRAULIC SYSTEM FILTERS
      HYDRAULIC CHECK-OUT PROCEDURE
   OPTIONS AND SPECIAL TOOLS
      FIRE CONTROL SYSTEMS
      SPECIAL TOOLS
      PAYLOAD METER III
      RESERVE ENGINE OIL SYSTEM
   CAB COMPONENTS
      TRUCK CAB
      CAB COMPONENTS
      OPERATOR COMFORT
      OPERATOR CAB CONTROLS
   LUBRICATION AND SERVICE
      LUBRICATION AND SERVICE
      AUTOMATIC LUBRICATION SYSTEM
   ALPHABETICAL INDEX
   SYSTEM SCHEMATICS
      HYDRAULIC SUPPLY AND BRAKE COOLING SCHEMATIC - HH347
      HYDRAULIC BRAKE SYSTEM SCHEMATIC - HH352
      PLM III ELECTRICAL SYSTEM SCHEMATIC - HE479
      PLM III HOOK-UP WIRING - HE483
      ELECTRICAL SCHEMATIC - XS0500
