Komatsu HD1500-7 (SN: A30001-30084) Rigid Dump Trucks with SDA12V160 Engines (USA) Workshop Manual (CEBM019905)

Illustrated factory Workshop Manual for Komatsu Rigid Dump Trucks Models HD1500-7.

This manual will assist you in diagnosing, repairing, and adjusting for your rigid dump truck.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models (USA):
   HD1500-7 (SN: A30001-30048; A30056-30057; A30065-30066; A30071-30072; A30076-30077; A30081-30084)

Format: PDF, 1392 pages
Language: English
Table of Contents:
   GENERAL INFORMATION
      A2 - MAJOR COMPONENTS AND SPECIFICATIONS
      A3 - GENERAL SAFETY AND OPERATION
      A4 - WARNINGS AND CAUTIONS
      A5 - TORQUE TABLES AND CONVERSION CHARTS
      A7 - STORAGE PROCEDURES
   STRUCTURES
      B2 - STRUCTURAL COMPONENTS
      B3 - DUMP BODY
      B4 - FUEL TANK
   ENGINE
      C3 - COOLING SYSTEM
      C4 - ENGINE
      C5 - AIR FILTRATION SYSTEM
      C7 - FAN CLUTCH
   ELECTRICAL SYSTEM
      D2 - BATTERIES AND STARTING SYSTEM
      D3 - ELECTRICAL SYSTEM COMPONENTS
      D10 - CHARGING SYSTEM
      D11 - AUTOMATIC TRANSMISSION CONTROLLER
      D15 - MACHINE MONITOR
      D20 - FAILURE CODES
      D21 - TROUBLESHOOTING
      D30 - VHMS INITIALIZATION
      D31 - VEHICLE HEALTH MONITORING SYSTEM (VHMS)
   TRANSMISSION/TORQUE CONVERTER
      F2 - TORQUE CONVERTER AND TRANSMISSION
      F2 - TORQUE CONVERTER AND TRANSMISSION (-40°C)
      F3 - TRANSMISSION OIL COOLER & STRAINERS
      F5 - DRIVE SHAFTS
      F8 - TORQUE CONVERTER REBUILD
      F8 - TORQUE CONVERTER REBUILD (-40°C)
      F9 - TRANSMISSION REBUILD
   DRIVE AXLE, SPINDLES AND WHEELS
      G2 - TIRES AND RIMS
      G3 - FRONT WHEEL HUB AND SPINDLE
      G4 - REAR AXLE ATTACHMENTS
      G5 - REAR AXLE AND FINAL DRIVE ASSEMBLY
      G6 - FINAL DRIVE PLANETARIES AND WHEEL HUBS
   SUSPENSIONS
      H2 - FRONT SUSPENSION
      H3 - REAR SUSPENSION
      H4 - SUSPENSION OILING AND CHARGING
   BRAKE SYSTEM
      J2 - BRAKE SYSTEM OPERATION
      J3 - BRAKE CIRCUIT COMPONENT SERVICE
      J4 - BRAKE CIRCUIT CHECKOUT
      J5 - FRONT WET DISC BRAKES
      J6 - REAR WET DISC BRAKES
      J7 - PARKING BRAKE
   HYDRAULIC SYSTEM
      L2 - HYDRAULIC SYSTEM OVERVIEW
      L3 - HYDRAULIC SYSTEM COMPONENT REPAIR
      L4 - STEERING CIRCUIT
      L5 - STEERING CONTROL UNIT
      L6 - STEERING CIRCUIT COMPONENT REPAIR
      L7 - HOIST CIRCUIT
      L8 - HOIST CIRCUIT COMPONENT REPAIR
      L9 - HYDRAULIC SYSTEM FILTERS
      L10 - HYDRAULIC CHECK-OUT PROCEDURE
   OPTIONS AND SPECIAL TOOLS
      M7 - HOT START SYSTEM
      M8 - SPECIAL TOOLS
   OPERATOR CAB
      N2 - OPERATOR CAB
      N3 - CAB COMPONENTS
      N4 - HEATING AND AIR CONDITIONING
      N5 - OPERATOR CAB AND CONTROLS
   LUBRICATION AND SERVICE
      P2 - LUBRICATION AND SERVICE
      P3 - AUTOMATIC LUBRICATION SYSTEM
   SYSTEM SCHEMATICS
      HYDRAULIC SYSTEM SCHEMATIC
      HYDRAULIC SYSTEM SCHEMATIC (COLD WEATHER -40°C)
      BRAKE SYSTEM SCHEMATIC
      HOOKUP SCHEMATIC
      ELECTRICAL WIRING SCHEMATIC
      CONNECTOR LOCATOR
