Komatsu 3D82AE-5, (S)3D84E-5, 3D88E-5, 4D84E-5, (S)4D88E-5, 4D94LE-2, (S)4D98E Diesel Engines Workshop Manual (SEBM035103)

Illustrated factory Workshop Manual for Komatsu Diesel Engines Models 3D82AE-5, 3D84E-5, 3D88E-5, 4D84E-5, 4D88E-5, 4D94LE-2, 4D98E, S3D84E-5, S4D88E-5 and S4D98E.

This manual will assist you in diagnosing, repairing, and adjusting for your diesel engine.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models (Japan):
   3D82AE-5
   3D84E-5
   3D88E-5
   4D84E-5
   4D88E-5
   4D94LE-2
   4D98E
   S3D84E-5
   S4D88E-5
   S4D98E

Format: PDF, 197 pages
Language: English
Table of Contents:
   GENERAL
      SPECIFICATIONS
      ENGINE EXTERNAL VIEWS
      STRUCTURAL DESCRIPTION
   INSPECTION ANG ADJUSTMENT
      PERIODIC MAINTENANCE SCHEDULE
      PERIODIC INSPECTION AND MAINTENANCE PROCEDURE
      ADJUSTING THE NO-LOAD MAXIMUM OR MINIMUM SPEED
      SENSOR INSPECTION
      WATER LEAK CHECK IN COOLING WATER SYSTEM
      RADIATOR CAP INSPECTION
      THERMOSTAT INSPECTION
      ADJUSTING OPERATION
      LONG STORAGE
   TROUBLESHOOTING
      PREPARATION BEFORE TROUBLESHOOTING
      QUICK REFERENCE TABLE FOR TROUBLESHOOTING
      TROUBLESHOOTING BY MEASURING COMPRESSION PRESSURE
   DISASSEMBLY, INSPECTION AND REASSEMBLY OF ENGINES
      COMPLETE DISASSEMBLY AND REASSEMBLY
      CYLINDER HAED: DISASSEMBLY, INSPECTION AND REASSEMBLY
      GEAR TRAIN AND CAMSHAFT
      CYLINDER BLOCK
   LUBRICATION SYSTEM
      LUBRICATION SYSTEM DIAGRAM
      TROCHOID PUMP COMPONENTS
      DISASSEMBLY (REVERSE THE PROCEDURE BELOW FOR ASSEMBLY)
      SERVICING POINTS
      PARTS INSPECTION AND MEASUREMENT
   COOLING SYSTEM
      COOLING WATER SYSTEM
      COOLING WATER PUMP COMPONENTS
      DISASSEMBLY (REVERSE THE PROCEDURE BELOW FOR ASSEMBLY)
      SERVICING POINTS
   FUEL INJECTION PUMP/GOVERNOR
      INTRODUCTION
      FUEL INJECTION PUMP
   TURBOCHARGER
      STRUCTURE AND FUNCTIONS
      SERVICE STANDARDS AND TIGHTENING TORQUE
      PERIODIC INSPECTION PROCEDURE
      DISASSEMBLY PROCEDURE
      WASHING AND INSPECTION PROCEDURE
      REASSEMBLY PROCEDURE
      HANDING AFTER DISASSEMBLY AND REASSEMBLY
      TROUBLESHOOTING
   STARTING MOTOR
      FOR 4D94LE/(S)4D98E
   ALTERNATOR
      THE 40A ALTERNATOR FOR 3D84E AND OTHER MODELS
   ELECTRIC WIRING
      ELECTRIC WIRING DIAGRAM
      PRECAUTION ON ELECTRIC WIRING
   SERVICE STANDARDS
      ENGINE TUNING
      ENGINE BODY
      LUBRICATING OIL SYSTEM (TROCHOID PUMP)
   TIGHTENING TORQUE FOR BOLTS AND NUTS
      TIGHTENING TORQUES FOR MAIN BOLTS AND NUTS
      TIGHTENING TORQUES FOR STANDARD BOLTS AND NUTS
