Komatsu PC30MR-5 (SN from 50001) and PC35MR-5 (SN from 30001) Compact Excavators Workshop Manual (SEN06591-07)

Illustrated factory Workshop Manual for Komatsu Compact Excavators Models PC30MR-5 and PC35MR-5.

This manual will assist you in diagnosing, repairing, and adjusting for your compact excavator.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models:
   PC30MR-5 (SN: 50001-)
   PC35MR-5 (SN: 30001-)

Format: PDF, 1504 pages
Language: English
Table of Contents:
   COVER
   INDEX AND FOREWORD
      INDEX
      ABBREVIATION LIST
      FOREWORD, SAFETY, BASIC INFORMATION
   SPECIFICATIONS
      ABBREVIATION LIST
      SPECIFICATIONS
   STRUCTURE AND FUNCTION
      ABBREVIATION LIST
      BOOT-UP SYSTEM
      ENGINE SYSTEM
      COOLING SYSTEM
      CONTROL SYSTEM
      HYDRAULIC SYSTEM
      WORK EQUIPMENT SYSTEM
      SWING SYSTEM
      TRAVEL SYSTEM
      UNDERCARRIAGE AND FRAME
      WORK EQUIPMENT
      CAB AND ITS ATTACHMENTS
   STANDARD VALUE TABLE
      ABBREVIATION LIST
      STANDARD VALUE TABLE FOR ENGINE
      STANDARD VALUE TABLE FOR MACHINE
   TESTING AND ADJUSTING
      ABBREVIATION LIST
      RELATED INFORMATION ON TESTING AND ADJUSTING
      ENGINE AND COOLING SYSTEM
      POWER TRAIN
      UNDERCARRIAGE AND FRAME
      HYDRAULIC SYSTEM
      CAB AND ITS ATTACHMENTS
      ELECTRICAL SYSTEM
      Pm CLINIC
   TROUBLESHOOTING
      ABBREVIATION LIST
      RELATED INFORMATION ON TROUBLESHOOTING
      TROUBLESHOOTING BY FAILURE CODE (DISPLAY OF CODE)
      TROUBLESHOOTING OF ELECTRICAL SYSTEM (E-MODE)
      TROUBLESHOOTING FOR HYDRAULIC AND MECHANICAL SYSTEMS (H MODE)
      TROUBLESHOOTING OF ENGINE (S-MODE)
   DISASSEMBLY AND ASSEMBLY
      ABBREVIATION LIST
      RELATED INFORMATION ON DISASSEMBLY AND ASSEMBLY
      ENGINE AND COOLING SYSTEM
      POWER TRAIN
      UNDERCARRIAGE AND FRAME
      HYDRAULIC SYSTEM
      WORK EQUIPMENT
      CAB AND ITS ATTACHMENTS
      ELECTRICAL SYSTEM
   MAINTENANCE STANDARD
      ABBREVIATION LIST
      ENGINE AND COOLING SYSTEM
      POWER TRAIN
      UNDERCARRIAGE AND FRAME
      HYDRAULIC SYSTEM
      WORK EQUIPMENT
   APPENDIX
      ABBREVIATION LIST
      AIR CONDITIONER SYSTEM
      COMPONENT PARTS OF AIR CONDITIONER SYSTEM
      INFORMATION DESCRIBED IN TROUBLESHOOTING TABLE
      A-1 TROUBLESHOOTING FOR POWER SUPPLY SYSTEM (AIR CONDITIONER DOES NOT OPERATE)
      A-2 TROUBLESHOOTING FOR BLOWER MOTOR SYSTEM (NO AIR COMES OUT OR AIR FLOW IS ABNORMAL)
      A-3 TROUBLESHOOTING FOR TEMPERATURE CONTROL FUNCTION
      A-4 TROUBLESHOOTING FOR AIR CONDITINOER COMPRESSOR AND COOLING SYSTEM (ELECTRICAL SYSTEM)
      A-5 TROUBLESHOOTING FOR AIR CONDITINOER COMPRESSOR AND COOLING SYSTEM (MECHANICAL SYSTEMS)
      A-6 TROUBLESHOOTING FOR HOT WATER CIRCUIT SYSTEM
      A-7 UNUSUAL NOISE IS HEARD FROM AIR CONDITINOER RELATED PARTS
      A-8 WATER LEAKS FROM AIR CONDITINOER RELATED PARTS
      A-9 TROUBLESHOOTING FOR FRESH/RECIRC AIR CHANGEOVER
      PRECAUTIONS FOR DISCONNECTING AND CONNECTING HOSES AND TUBES IN AIR CONDITIONER PIPINGS
      HANDLE COMPRESSOR OIL
   CIRCUIT DIAGRAMS
      ABBREVIATION LIST
      HYDRAULIC CIRCUIT DIAGRAM
      ELECTRICAL CIRCUIT DIAGRAM
   INDEX
