Komatsu PC200LC-8 and PC220LC-8 (SN: A88001-90300) Crawler Excavators with SAA6D107E-1 engines Workshop Manual (CEBM000903)

Illustrated factory Workshop Manual for Komatsu Crawler Excavators Models PC200LC-8 and PC220LC-8.

This manual will assist you in diagnosing, repairing, and adjusting for your crawler excavator.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models (USA):
   PC200LC-8 (SN: A88001-90300)
   PC220LC-8 (SN: A88001-90300)

Format: PDF, 1195 pages
Language: English
Table of Contents:
   CEMB000903 PC200/220LC-8
      REVISED PAGES
      SAFETY
      GENERAL
      HOW TO READ THE SHOP MANUAL
      HOISTING INSTRUCTIONS
      PUSH PULL COUPLER
      COATING MATERIALS
      STANDARD TIGHTENING TORQUE
      ELECTRIC WIRE CODE
      CONVERSION TABLES
   GENERAL
      SPECIFICATION AND TECHNICAL DATA
   STRUCTURE, FUNCTION AND MAINTENANCE STANDARD
      ENGINE AND COOLING SYSTEM
      POWER TRAIN
      UNDERCARRIAGE AND FRAME
      HYDRAULIC SYSTEM
      WORK EQUIPMENT
      CAB AND ITS ATTACHMENTS
      ELECTRICAL SYSTEM
      MONITOR SYSTEM
      SENSOR
      KOMTRAX TERMINAL SYSTEM
   STANDARD VALUE TABLES
      STANDARD SERVICE VALUE TABLE
   TESTING AND ADJUSTING
      SPECIAL TOOL LIST
      ENGINE COMPONENTS
      AIR CONDITIONER COMPRESSOR BELT TENSION
      FAN BELT
      SWING CIRCLE BEARING CLEARANCE
      TRACK SHOE TENSION
      OIL PRESSURE IN WORK EQUIPMENT, SWING, AND TRAVEL CIRCUITS
      CONTROL CIRCUIT BASIC PRESSURE
      OIL PRESSURE IN PUMP PC CONTROL CIRCUIT
      OIL PRESSURE IN PUMP LS CONTROL CIRCUIT
      SOLENOID VALVE OUTPUT PRESSURE
      PPC VALVE OUTPUT PRESSURE
      WORK EQUIPMENT HYDRAULIC DRIFT
      RELEASING RESIDUAL PRESSURE FROM HYDRAULIC CIRCUIT
      OIL LEAKAGE
      BLEEDING AIR FROM EACH PART
      CAB TIPPING STOPPER
      MIRRORS
      REAR VIEW CAMERA
      MACHINE MONITOR SPECIAL FUNCTIONS
      HANDLING VOLTAGE CIRCUIT OF ENGINE CONTROLLER
      PREPARING FOR ELECTRICAL SYSTEM TROUBLESHOOTING
      PROCEDURE FOR TESTING DIODES
      PM CLINIC SERVICE
   TROUBLESHOOTING
      GENERAL INFORMATION
      FAILURE CODE (DISPLAY OF CODE)
      ELECTRICAL SYSTEM (E-MODE)
      HYDRAULIC AND MECHANICAL SYSTEM (H-MODE)
   DISASSEMBLY AND ASSEMBLY
      HOW TO READ THIS SECTION
      SPECIAL TOOLS LIST
      SKETCHES OF SPECIAL TOOLS
      CONNECTOR REPAIR PROCEDURES
      ENGINE AND COOLING SYSTEM
      POWER TRAIN
      UNDERCARRIAGE AND FRAME
      HYDRAULIC SYSTEM
      WORK EQUIPMENT
      CAB AND ITS ATTACHMENTS
      ELECTRICAL SYSTEM
   AIR CONDITIONER
      STRUCTURE AND FUNCTION
      TESTING AND ADJUSTING
      TROUBLESHOOTING
   DIAGRAMS AND SCHEMATICS
      Hydraulic circuit diagram
      Hydraulic circuit diagram
      Electrical circuit diagram
      Connector arrangement diagram
      Electrical circuit diagram for air conditioner
