Komatsu WA600-3-L (SN from A52001) 4WD Wheeled Loaders (USA) Workshop Manual (CEBM002801)

Illustrated factory Workshop Manual for Komatsu 4WD Wheeled Loaders Models WA600-3-L.

This manual will assist you in diagnosing, repairing, and adjusting for your 4wd wheeled loader.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models (USA):
   WA600-3-L (SN: A52001-)

Format: PDF, 894 pages
Language: English
Table of Contents:
   FOREWORD
      SAFETY
      GENERAL
      HOW TO READ THE SHOP MANUAL
      HOISTING INSTRUCTIONS
      COATING MATERIALS
      STANDARD TIGHTENING TORQUE
      ELECTRIC WIRE CODE
      CONVERSIONS TABLES
   GENERAL
      GENERAL ASSEMBLY DRAWING
      SPECIFICATIONS
      WEIGHT TABLE
      FUEL, COOLANT AND LUBRICANTS ACCORDING TO AMBIENT TEMPERATURE
   STRUCTURE AND FUNCTION
      GENERAL POWER TRAIN
      POWER TRAIN SYSTEM
      RADIATOR, HYDRAULIC OIL COOLER
      TORQUE CONVERTER AND TRANSMISSION PIPING
      HYDRAULIC CIRCUIT FOR POWER TRAIN
      HYDRAULIC CIRCUIT DIAGRAM FOR POWER TRAIN
      TORQUE CONVERTER
      TRANSMISSION
      PILOT OIL FILTER
      PILOT REDUCING VALVE
      PRIORITY VALVE
      MODULATING VALVE AND QUICK RETURN VALVE
      REDUCING VALVE
      ACCUMULATOR VALVE
      EMERGENCY MANUAL SPOOL
      LUBRICATION BYPASS VALVE
      HYDRAULIC CIRCUIT SCHEMATIC
      TRANSFER
      DRIVE SHAFTS
      CENTER SUPPORT
      CENTER HINGE PIN
      AXLE
      DIFFERENTIAL
      FINAL DRIVE
      STEERING
      GROUND-DRIVEN STEERING
      BRAKE SYSTEM
      PARKING BRAKE
      HYDRAULIC PIPING
      WORK EQUIPMENT
      HYDRAULIC TANK
      PPC SYSTEM
      CUT-OFF VALVE
      MAIN CONTROL VALVE
      WORK EQUIPMENT - LUBRICATION
      WORK EQUIPMENT - LINKAGE
      BUCKET
      BUCKET POSITIONER AND BOOM KICK-OUT
      ROPS CANOPY
      CAB
      AIR CONDITIONER
      ELECTRICAL
      MACHINE MONITOR SYSTEM
      ENGINE STARTING CIRCUIT
      ENGINE STOP CIRCUIT
      ETHER START CIRCUIT
      ELECTRIC TRANSMISSION CONTROL
      ELECTRIC PARKING BRAKE
      ENGINE DIAGNOSTICS
   TESTING, ADJUSTING AND TROUBLESHOOTING
      STANDARD VALUE TABLE FOR ENGINE IN CHASSIS
      STANDARD VALUE TABLE FOR CHASSIS
      STANDARD VALUE TABLE FOR ELECTRICAL SYSTEM
      TESTING AND ADJUSTING
      TROUBLESHOOTING: GENERAL INFORMATION
      TROUBLESHOOTING THE TRANSMISSION CONTROLLER SYSTEM (T MODE)
      TROUBLESHOOTING THE MAIN MONITOR SYSTEM (M MODE)
      TROUBLESHOOTING THE MAINTENANCE MONITOR SYSTEM (K MODE)
      TROUBLESHOOTING THE ELECTRICAL SYSTEM (E MODE)
      TROUBLESHOOTING THE HYDRAULIC AND MECHANICAL SYSTEMS (H MODE)
      TROUBLESHOOTING THE JOYSTICK STEERING CONTROLLER SYSTEM (J MODE)
   DISASSEMBLY AND ASSEMBLY
      HOW TO USE THIS MANUAL
      PRECAUTIONS WHEN CARRYING OUT THESE OPERATIONS
      SPECIAL TOOL LIST
      ILLUSTRATIONS OF SPECIAL TOOLS
      STARTING MOTOR
      ALTERNATOR
      ENGINE OIL COOLER
      FUEL INJECTION PUMP
      WATER PUMP
      NOZZLE HOLDER
      TURBOCHARGER
      RADIATOR
      ENGINE AND TORQUE CONVERTER ASSEMBLY
      TORQUE CONVERTER
      TRANSMISSION
      TRANSMISSION VALVE
      TRANSFER
      CENTER SUPPORT
      DRIVE SHAFT
      FRONT AXLE
      FRONT DIFFERENTIAL
      REAR AXLE
      REAR DIFFERENTIAL
      DIFFERENTIAL GEAR ASSEMBLY
      FINAL DRIVE
      STEERING CONTROL VALVE
      STEERING CYLINDER
      STEERING VALVE
      CUT-OFF VALVE
      BRAKE VALVE
      BRAKE VALVE (RIGHT SIDE)
      BRAKE VALVE (LEFT SIDE)
      SLACK ADJUSTER
      BRAKE
      HYDRAULIC PUMP
      HYDRAULIC TANK
      HYDRAULIC FILTER
      PPC VALVE
      WORK EQUIPMENT VALVE
      MAIN CONTROL VALVE
      DUMP CYLINDER
      LIFT CYLINDER
      LIFT CYLINDER AND DUMP CYLINDER
      CENTER HINGE PIN
      WORK EQUIPMENT
      BULKHEAD
      FLOOR FRAME
      COUNTERWEIGHT
      FUEL TANK
      CAB
      STOP VALVE
      ACCUMULATOR
      ACCUMULATOR CHARGE VALVE
      PARKING BRAKE SOLENOID VALVE
      DIVERTER VALVE
      GROUND-DRIVEN STEERING PUMP
      PARKING BRAKE
      PARKING BRAKE CALIPERS
      PARKING BRAKE PAD
      REAR TIRES
      AIR CONDITIONER COMPRESSOR
      AIR CONDITIONER CONDENSER
      RECEIVER TANK
      AIR CONDITIONER UNIT
      MONITOR
   MAINTENANCE STANDARD
      ENGINE MOUNT
      TRANSMISSION MOUNT
      TORQUE CONVERTER
      TRANSMISSION
      TRANSFER
      DRIVE SHAFT
      CENTER SUPPORT
      CENTER HINGE PIN
      AXLE MOUNT
      DIFFERENTIAL
      FINAL DRIVE
      STEERING
      BRAKES
      HYDRAULICS
      WORK EQUIPMENT
      ROPS CANOPY
