Komatsu WA600-3-LK (SN from A53001) 4WD Wheeled Loaders (USA) Workshop Manual (CEBM005502)

Illustrated factory Workshop Manual for Komatsu 4WD Wheeled Loaders Models WA600-3-LK.

This manual will assist you in diagnosing, repairing, and adjusting for your 4wd wheeled loader.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models (USA):
   WA600-3-LK (SN: A53001-)

Format: PDF, 1032 pages
Language: English
Table of Contents:
   FOREWORD
      SAFETY
      GENERAL
      HOW TO READ THE SHOP MANUAL
      HOISTING INSTRUCTIONS
      PUSH-PULL TYPE COUPLER
      COATING MATERIALS
      STANDARD TIGHTENING TORQUE
      ELECTRIC WIRE CODE
      CONVERSION TABLES
   GENERAL
      DIMENSIONS
      SPECIFICATIONS
      WEIGHT TABLE
      FUEL, COOLANT AND LUBRICATNTS
   STRUCTURE AND FUNCTION
      GENERAL POWER TRAIN
      POWER TRAIN SYSTEM
      RADIATOR, HYDRAULIC OIL COOLER
      TORQUE CONVERTER AND TRANSMISSION PIPING
      HYDRAULIC CIRCUIT FOR POWER TRAIN
      TORQUE CONVERTER
      TRANSMISSION
      TRANSFER
      DRIVE SHAFT
      CENTER SUPPORT
      CENTER HINGE PIN
      AXLE
      DIFFERENTIAL
      FINAL DRIVE
      STEERING
      BRAKE
      PARKING BRAKE
      HYDRAULIC
      WORK EQUIPMENT
      ROPS CANOPY
      CAB
      AIR CONDITIONER
      ELECTRICAL CIRCUIT DIAGRAM
      MACHINE MONITOR SYSTEM
      JOYSTICK AND AUTOMATIC SHIFT CONTROL
      ENGINE STARTING CIRCUIT
      ENGINE STOP CIRCUIT
      PRE-HEATING CIRCUIT
      ELECTRIC TRANSMISSION CONTROL
      ELECTRIC PARKING BRAKE CONTROL
      ECSS SYSTEM
   TESTING, ADJUSTING AND TROUBLESHOOTING
      STANDARD VALUE TABLE
      SERVICE TOOLS - TESTING, ADJUSTING & TROUBLESHOOTING
      ENGINE SPEEDS
      TORQUE CONVERTER
      ENGINE
      EXHAUST GAS COLOR
      AIR CONDITIONER COMPRESSOR
      ACCELERATOR PEDAL
      TORQUE CONVERTER OIL PRESSURE
      TRANSMISSION OIL PRESSURE
      FLUSHING THE TORQUE CONVERTER AND TRANSMISSION HYDRAULIC CIRCUIT
      FAILED TRANSMISSION VALVE
      STEERING WHEEL
      BRAKE
      PARKING BRAKE
      PPC OIL PRESSURE
      WORK EQUIPMENT
      MACHINE MONITOR (SPEEDOMETER MODULE)
      BLEEDING AIR
      WHEELS AND TIRES
      ADJUSTING JOYSTICK LEVER POTENTIOMETER
      ADJUSTING JOYSTICK LEVER NEUTRAL DETECTION SWITCH
      TROUBLESHOOTING GENERAL
      TROUBLESHOOTING CONNECTORS
      TROUBLESHOOTING SYSTEMS OF ECSS (D-MODE)
      TROUBLESHOOTING OF ELECTRICAL SYSTEM (E-MODE)
      TROUBLESHOOTING ENGINE CONTROLLER SYSTEM (EA-MODE)
      TROUBLESHOOTING OF HYDRAULIC AND MECHANICAL SYSTEMS (H-MODE)
      TROUBLESHOOTING OF JOYSTICK STEERING CONTROLLER SYSTEM (J-MODE)
      TROUBLESHOOTING OF MAINTENANCE MONITOR SYSTEM (K-MODE)
      TROUBLESHOOTING OF MAIN MONITOR SYSTEM (M-MODE)
      TROUBLESHOOTING ENGINE MECHANICAL SYSTEM (S-MODE)
      TROUBLESHOOTING OF TRANSMISSION CONTROLLER SYSTEM (T-MODE)
      TROUBLESHOOTING AIR CONDITIONER (DENSO)
      TROUBLESHOOTING ENGINE FAULT DIAGNOSTICS
   DISASSEMBLY AND ASSEMBLY
      METHOD OF USING MANUAL
      PRECAUTIONS DURING OPERATION
      SPECIAL TOOL LIST
      SKETCHES OF SPECIAL TOOLS
      ENGINE
      RADIATOR
      ENGINE AND TORQUE CONVERTER
      TORQUE CONVERTER
      TRANSMISSION
      TRANSFER
      CENTER SUPPORT
      DRIVE SHAFT
      FRONT AXLE
      REAR AXLE
      DIFFERENTIAL
      FINAL DRIVE
      STEERING
      GROUND-DRIVEN STEERING
      BRAKE
      PARKING BRAKE
      HYDRAULICS
      CENTER HINGE PIN
      WORK EQUIPMENT
      BULKHEAD
      FLOOR FRAME
      CAB
      MONITOR
      AIR CONDITIONER
      FUEL TANK
      COUNTERWEIGHT
      FRONT TIRES
      REAR TIRES
   MAINTENANCE STANDARD
      ENGINE MOUNT
      TRANSMISSION MOUNT
      TORQUE CONVERTER
      TRANSMISSION
      TRANSFER
      DRIVE SHAFT
      CENTER SUPPORT
      CENTER HINGE PIN
      AXLE MOUNT
      DIFFERENTIAL
      FINAL DRIVE
      STEERING
      BRAKES
      HYDRAULIC
      WORK EQUIPMENT
      ROPS CANOPY
   OTHERS
      HYDRAULIC
      ELECTRICAL
