Komatsu FB30-2 (SN from 10001) and FB30S-2 (SN from 20001) Electric Forklift Trucks Workshop Manual (FB30_30S.2-BE1)

Illustrated factory Workshop Manual for Komatsu Electric Forklift Trucks Models FB30-2 and FB30S-2.

This manual will assist you in diagnosing, repairing, and adjusting for your electric forklift truck.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models:
   FB30-2 (SN: 10001-)
   FB30S-2 (SN: 20001-)

Format: PDF, 224 pages
Language: English
Table of Contents:
   GENERAL
      General views
      Specifications
      General assembly drawing
   SAFETY OPERATION
      GENERAL INSTRUCTIONS FOR SAFETY
      HANDLING OF REGULAR TOOLS
      HANDLING OF HEAVY PARTS
   REMOVAL AND INSTALLATION OF UNITS
      Flow chart of removal and installation
      Units to be removed after dismounting counterweight
         Overhead guard
         Counterweight
         Rear axle
      Units inside frame
         Battery
         Power steering cylinder
         Hydraulic pump
         Pump motor
         Power steering motor
         Tilt cylinder
         Mast
         Power train assembly
         Steering gear box
      Units outside frame
         Lift cylinder
         Front wheel and rear wheel
         Wheel brake
      Electrical devices
         Wiring diagram
         Wiring inside dashboard
         Wiring inside main controller
         Accelerator
      Commonality of component parts
   DISASSEMBLY AND ASSEMBLY
      Drive system
         General
         Transfer
         Differential and front axle
         Front wheel and rear wheel
      Steering system
         General
         Steering gear box
         Power steering cylinder
         Rear axle
         Power steering pump
      Brake system
         General
         Operation of wheel brake
         Disassembly of wheel brake
         Assembly of wheel brake
         Adjustment of wheel brake
         Adjustment of air bleeding
      Work equipment
         Mast
         Hydraulic pump
         Control valve
         Lift cylinder
         Down control valve and safety valve.
         Tilt cylinder and power steering cylinder
   ELECTRICAL SYSTEM
      General
      Electrical components
      Battery
         A) Dimensions limit
         B) Recommended battery makers
      Controller
         A) Overall structure
         B) Function of controller
         C) Function and adjustment of modules A and B .
         D) Auxiliary systems ..
      Motor
         Drive motor
         Pump motor
         PS motor
      Battery charger
         A) Handling of electromagnetic switch
         B) Haldling of timer fuse
         C) Hanlding of diode and charge controller
         D) Handling transformer
   TROUBLESHOOTING
      Controller
      Description
      FB30-2 (Outdoor type);
      Chart of check point and voltage
      Troubleshooting chart
      FB30S-2 (Indoor type);
      Chart of check point and voltage
      Troubleshooting chart
      Charger
      Wiring diagram
      Troubleshooting chart
