Komatsu D61EX-12 and D61PX-12 (SN from 1001, B1001) Crawler Dozers Workshop Manual (SEBM018906)

Illustrated factory Workshop Manual for Komatsu Crawler Dozers Models D61EX-12 and D61PX-12.

This manual will assist you in diagnosing, repairing, and adjusting for your crawler dozer.
You can use a Windows, Mac, or Android device to view this manual. You only need to have a PDF reader installed.

Covered Models:
   D61EX-12 (SN: 1001-; B1001-)
   D61PX-12 (SN: 1001-; B1001-)

Format: PDF, 716 pages
Language: English
Table of Contents:
   SAFETY
   FORWARD
   GENERAL
      SPECIFICATION DRAWING
      SPECIFICATIONS
      WEIGHT TABLE
      TABLE OF FUEL COOLANT AND LUBRICANTS
   STRUCTURE AND FUNCTION
      RADIATOR, POWER TRAIN, OIL COOLER
      ENGINE CONTROL
      POWER TRAIN SYSTEM
      POWER TRAIN SKELETON
      POWER TRAIN UNIT
      POWER TRAIN HYDRAULIC PIPING DIAGRAM
      DAMPER, UNIVERSAL JOINT
      TORQUE CONVERTER AND PTO
      TRANSMISSION CONTROL
      TRANSMISSION
      TRANSMISSION CONTROL VALVE
      MAIN RELIEF VALVE
      LUBRICATION RELIEF VALVE
      STEERING AND BRAKE CONTROL
      BEVEL GEAR SHAFT, HSS STEERING, STEERING BRAKE
      BRAKE VALVE
      SCAVENGING PUMP STRAINER
      POWER TRAIN OIL STRAINER
      POWER TRAIN OIL FILTER
      FINAL DRIVE
      MAIN FRAME
      TRACK FRAME
      RECOIL SPRING
      SUSPENSION
      WORK EQUIPMENT HYDRAULIC PIPING DIAGRAM
      PPC CONTROL PIPING DIAGRAM
      WORK EQUIPMENT CONTROL
      HYDRAULIC TANK AND FILTER
      HYDRAULIC AND HSS PUMP SERIAL NO. 1001 - 1173, SERIAL NO. B1001 - B3000, MODEL HPV82
      HYDRAULIC AND HSS PUMP SERIAL NO. B3001 AND UP MODEL: HPV95
      SERVO VALVE
      PPC VALVE SERIAL NO. 1001 - 1173, SERIAL NO. B1001 - B3000
      PPC VALVE SERIAL NO. B3001 AND UP
      PPC CHARGE VALVE
      MAIN CONTROL VALVE SERIAL NO. 1001 - 1173, SERIAL NO. B1001 - B3000
      MAIN CONTROL VALVE SERIAL NO. B3001 AND UP
      CLSS
      HSS MOTOR SERIAL NO. 1001 - 1173, SERIAL NO. B1001 - B3000
      HSS MOTOR SERIAL NO. B3001 AND UP
      SUCTION VALVE
      WORK EQUIPMENT
      ENGINE CONTROL
      MACHINE MONITOR SYSTEM
      SENSORS
   TESTING AND ADJUSTING
      STANDARD VALUE TABLE FOR ENGINE
      STANDARD VALUE TABLE FOR CHASSIS
      STANDARD VALUE TABLE FOR ELECTRICAL SYSTEM
      TESTING AND ADJUSTING
      TROUBLESHOOTING
   DISASSEMBLY AND ASSEMBLY
      METHOD OF USING MANUAL
      PRECAUTIONS WHEN CARRYING OUT OPERATION
      SPECIAL TOOL LIST
      SKETCHES OF SPECIAL TOOLS
      ENGINE
      RADIATOR AND GAURD
      RADIATOR
      HYDRAULIC OIL COOLER
      FUEL TANK
      DAMPER
      PTO, TORQUE CONVERTER AND TRANSMISSION
      PTO
      TORQUE CONVERTER
      TORQFLOW TRANSMISSION
      TORQUE CONVERTER MAIN RELIEF VALVE
      TRANSMISSION CONTROL VALVE
      STEERING BRAKE
      HSS
      BRAKE VALVE
      HSS MOTOR
      SCAVENGING PUMP
      POWER TRAIN AND LUBRICATING OIL PUMP
      FINAL DRIVE
      TRACK FRAME
      RECOIL SPRING
      IDLER
      TRACK ROLLER
      CARRIER ROLLER
      TRACK SHOE
      ONE LINK
      PIVOT SHAFT
      EQUALIZER BAR
      EQUALIZER BAR SIDE BUSHING
      SEGMENT TEETH
      HSS AND HYDRAULIC PUMP
      PPC PUMP AND PPC CHARGE RELIEF VALVE
      MAIN CONTROL VALVE
      STEERING PPC VALVE
      SUCTION VALVE
      BLADE ANGLE CYLINDER
      BLADE TILT CYLINDER
      BLADE LIFT CYLINDER
      HYDRAULIC CYLINDER
      WORK EQUIPMENT
      ROPS GUARD (ROPS CANOPY)
      DASHBOARD
      MONITOR PANEL
      FLOOR FRAME
   MAINTENANCE STANDARD
      DAMPER, UNIVERSAL JOINT
      TORQUE CONVERTER, PTO
      TRANSMISSION
      TRANSMISSION CONTROL VALVE
      MAIN RELIEF VALVE
      BEVEL GEAR SHAFT, HSS STEERING, BRAKE
      BRAKE VALVE
      WORK EQUIPMENT, HSS PUMP
      HSS MOTOR
      POWER TRAIN LUBRICATION PUMP
      PCC CONTROL PUMP
      PPC VALVE
      PPC CHARGE VALVE
      FINAL DRIVE
      TRACK FRAME, RECOIL SPRING
      IDLER
      TRACK ROLLER
      CARRIER ROLLER
      TRACK SHOE
      DIMENSIONS OF SHAPE OF SPROCKET TOOTH (ACTUAL SIZE)
      SUSPENSION
      MAIN CONTROL VALVE
      WORK EQUIPMENT CYLINDER
      WORK EQUIPMENT
      CUTTING EDGE AND BIT
      RIPPER
   OTHERS
      ELECTRIC CIRCUIT DIAGRAM FOR CAB
      POWER TRAIN HYDRAULIC CIRCUIT DIAGRAM
      STEERING- WORK EQUIPMENT HYDRAULIC CIRCUIT DIAGRAM SERIAL NO. 1001 - 1173, SERIAL NO. B1001 - B3000
      STEERING- WORK EQUIPMENT HYDRAULIC CIRCUIT DIAGRAM SERIAL NO. B3001 AND UP
      ELECTRIC CIRCUIT DIAGRAM SERIAL NO. 1001 - 1173, SERIAL NO. B1001 - B3000 CAB SPECIFICATION
      ELECTRIC CIRCUIT DIAGRAM SERIAL NO. B3001 AND UP CAB SPECIFICATION
      ELECTRIC CIRCUIT DIAGRAM SERIAL NO. 1001 - 1173, SERIAL NO. B1001 - B3000 CANOPY SPECIFICATION
      ELECTRIC CIRCUIT DIAGRAM SERIAL NO. B3001 CANOPY SPECIFICATION
